5-stand X-high stainless steel tandem cold mill
X-HIGH-5-STAND
5-stand X-high stainless steel tandem cold mill unit is suitable for the mass production of stainless steel strips. The strip steel is rolled and formed through multiple stands through the second flow control, with high strip precision and stable quality; the lead and tail are connected by a laser welding machine, and the yield is high; compared with a single machine Production reduces energy consumption and labor. Continuous mill production saves energy and reduces the cost per ton of steel while increasing output and quality.
Quantity
5-stand X-high stainless steel tandem cold mill
(1450mm Type)
GLIMPSE X-high 5-stand tandem cold mill unit is suitable for the mass production of stainless steel strips. The strip steel is rolled and formed through multiple stands through the second flow control, with high strip precision and stable quality; the lead and tail are connected by a laser welding machine, and the yield is high; compared with a single machine Production reduces energy consumption and labor. Continuous mill production saves energy and reduces the cost per ton of steel while increasing output and quality.
GLIMPSE X-high 5-stand tandem cold mill unit has three big advantages over other rolling units:
1. High productivity. The steel strip passes through multiple stand rolling mills and is rolled and formed at one time without any pauses in between. Compared with the reversing rolling mill, the continuous rolling mill has high production efficiency because the continuous rolling mill does not require multiple passes, and each rolling pass does not require deceleration and shutdown.
2. High yield. This tandem cold mill is continuous production, the front and rear steel coils are welded together at the head and tail, which can be directly rolled through by deceleration and decompression. Compared with the reversing rolling mill, the head and tail of each coil cannot be rolled, and therefore the yield of tandem cold mill is high.
3. Energy saving. Compared with the single-stand reversible rolling mill, the tandem rolling mill unit saves the configuration of multiple high-power rewinding and unwinding units, which greatly reduces the power consumption, so the power consumption per ton is reduced.
Main parameters of GLIMPSE X-high 5-stand tandem cold mill unit:
Material: Stainless steel HR NO.1 or CR annealed
Width: 800-1300mm
Input Thickness: 1.5-6.0mm
Finished Thickness: 0.2-2.0mm
Coil inner diameter: 610mm
Coil outer diameter: 900-2000mm
Coil weight: 25,000Kg Max (including sleeve)
Line speed: Entry 180m/min Exit 420m/min
Rolling speed: 400m/min
Capacity: 600,000 tons/year
The composition of GLIMPSE X-high 5-stand tandem cold mill unit:
Keywords:tandem cold mill, tandem mill, 18-high tandem mill, 5-stand tandem mill, X-high tandem mill
